Hoofdafbeelding Agilent G1316A 1260 TCC

Agilent G1316A 1260 TCC

Article nr.: 8085
Price on request


The Agilent 1260 Infinity Thermostatted Column Compartment is a stackable temperature-controlled column compartment for LC. It is used for heating and cooling to meet extreme requirements of retention time reproducibility.

G1316A 1260 Infinity TCC

The main features are:

  • Peltier heating and cooling from 10 degrees below ambient up to 80 °C with high heating and cooling speeds for maximum application flexibility and stability.
  • Holds up to three 30 cm columns and optimized design gives minimum dead volumes and maximum efficiency.
  • Two independently programmable heat exchangers contribute volumes of only 3 μL and 6 μL.
  • Electronic column-identification module as standard for GLP documentation of column type and major column parameters.
  • Optional high-quality Rheodyne® column switching valve with ceramic stator-face assemblies for prolonged lifetime.
Temperature range

10 degrees below ambient to 80 °C

up to 80 °C: flow rates up to 5 mL/min

Temperature stability ± 0.15 °C
Temperature accuracy

± 0.8 °C

± 0.5 °C

Warm-up/cool-down time 5 minutes from ambient to 40 °C
10 minutes from 40 – 20 °C
Dead volume

3 μL left heat exchanger

6 μL right heat exchanger

Communications Controller-area network (CAN), RS-232C, APG Remote: ready, start, stop and shut-down signals, LAN via other 1260 Infinity module
Safety and maintenanceExtensive diagnostics, error detection and display (through Instant Pilot and Agilent data system), leak detection, safe leak handling, leak output signal for shutdown of pumping system.
Low voltages in major maintenance areas.
GLP features Column-identification module for GLP documentation of column type.


Agilent HPLC system Agilent 1260 Infinity series
