Description
This Agilent GC/MS with ALS consists of the following components:
Agilent 6890N (G1530N)
The Agilent 6890N is a state-of-the- art gas chromatograph that provides superior performance for all applications. Key to its performance is the use of advanced electronic pneumatic control (EPC) modules and high performance temperature control. Each EPC unit is optimized for its intended use with a specific inlet and detector option.
Agilent 5975B inert XL MSD (G3172A)
| High vacuum pump | Performance
turbo |
| Optimal He column flow mL/min | 1 to 2 |
Maximum recommended gas flow
mL/min* | 4.0 |
| Maximum gas flow, mL/min† | 6.5 |
| Max column id | 0.53 mm
(30 m) |
| CI capability | No |
| DIP‡ capability (3rd party) | Yes |
* Total gas flow into the MSD: column flow plus reagent gas flow (if applicable).
† Expect degradation of spectral performance and sensitivity.
‡ Direct insertion probe.
Agilent ALS 7683B - G2613A Auto injector with G2914A 100 vial tray -
The 7683B Automatic Liquid Sampler (ALS) system is compatible with these Agilent gas chromatographs
- 4890 GC
- 5890A GCs that have been fully upgraded to a 5890 Series II instrument
(“fully” means that both electronic and mechanical upgrades have been
performed; a printed circuit board-only upgrade does not qualify). - 5890A Series II GC
- 6850 GC
- 6890A GC
- 6890 Plus GC
- 6890N GC
